SAFETY FEATURES

• Automatic short circuit shut off
• Automatic ground fault shut off
• Protection against “live power”
• Cable breakaway system
• Weather-resistant to withstand a variety of outdoor conditions
• Power surge protection

DEPENDABILITY

• Technology-based on more than 20 years of charging expertise
• Compliance with widely recognized connector standards
• EVSE-RS - Underwriters Laboratory listed
• 3-year standard on-site warranty (parts and labor)*
• ADA compliant installation

Plugs into a 6-50 receptacle

Plug-In: Yes
Hardwired: No
Cord Length: 25 feet
Dimensions: 12"L x 12"W x 8"D
Amperage: 30 Voltage: 208-240 VAC
Input/Output Power: 7.2 kW
Input Current: 30 Amps
Breaker Size: 40 Amps
Connector/Cable: SAE J1772
Mounting: Wall mount or pedestal
Weight: 21 lbs
Enclosure: NEMA 3R indoor/outdoor rated
Warranty: 3 years
